Visualize and Analyze 2D and 3D Data with UniPlot

_images/monitor.png

UniPlot is a state-of-the-art software to visualize and analyze data. With only a few mouse clicks, you can transform your data into 3D surface maps with color zones, contour maps with color fill, or plot 2D data into diagrams with several axes. Text objects, scanned photos and other drawing and labeling elements can be easily inserted into the document.

Data can be processed interactively or automated for repetitive tasks or analysis.

UniPlot offers an efficient and powerful programming language. It enables the user to add new functions to the user interface, to execute complex mathematical data analysis, to import specially formatted data files or to automatically produce complete documentations.

UniPlot can be used under Windows 8/10/11.

Please feel free to contact us (info@uniplot.com) with any questions or comments.

Solve Your Measurement Data Problems

Noisy signals, limit violations, hundreds of test files: the Engineering FAQ shows step by step how engineers solve them with UniPlot.

Noisy signal smoothed with a moving average and a Savitzky-Golay filter
How do I smooth a noisy signal?

Moving average, median and Savitzky-Golay filters, recalculated for every new file.

How do I smooth a noisy measurement signal with a moving average?
Engine speed with the points above a limit marked in red
Where does my signal exceed a limit?

Mark every limit violation in a long recording automatically.

How do I find the points where a signal overshoots or undershoots a limit?
Engine speed with a threshold and the duration of each event
How long was the signal above the limit?

Start time and duration of every event, as a table for the report.

How do I measure how long a signal stays above a limit?
Full load torque curves of five test files in one diagram
How do I compare many test files?

The same channel from every file in one diagram.

How do I compare the same channel from several measurement files?
Fuel consumption map as filled contour plot
How do I turn measured points into a map?

Contour maps and 3D surfaces from three channels.

How do I create an engine map from speed, torque and fuel consumption?
Stack of report pages
Can UniPlot create my reports automatically?

One template, one PDF per measurement file.

How do I create hundreds of PDF reports from measurement files automatically?

All questions of the Engineering FAQ

Did you know?

If you are a student, UniPlot is FREE. Contact us

You are not a student but want to try UniPlot? Get the test version now.

They use UniPlot

Some user success stories


For the full stories, visit our Success Story Center.
